NEX30606: 1.8V to 5.0V,600mA, 220nA ultra-low Iq Buck converter evaluation board
The NEX30606EVB is an evaluation board of NEX30606 with a simple and compact reference design. It provides convenient evaluation of NEX30606 16-step adjustable output voltage from 0.7V to 3.3V.
Key features and benefits
Input voltage range: 1.8 V to 5.0 V
Output voltage range: 0.7 V to 3.3 V (16-step adjustable voltage)
Output current: up to 600 mA
Use jumper to enable or disable output
Products on the board (1)
| Type number | Description | Status | Quick access | |
|---|---|---|---|---|
|
NEX30606UA | 1.8 V to 5.0 V, 600 mA, 220 nA ultra-low quiescent current, step-down converter | Production |
Products on the board (1)
| Type number | Description | Status | Quick access | |
|---|---|---|---|---|
|
|
NEX30606UA | 1.8 V to 5.0 V, 600 mA, 220 nA ultra-low quiescent current, step-down converter | Production |
Documentation (1)
| File name | Title | Type | Date |
|---|---|---|---|
| UM90042 | NEX30606 evaluation board: 1.8 V to 5.0 V, 600 mA, 220 nA ultra-low quiescent current, step-down converter | User manual | 2025-02-12 |
Support
If you are in need of design/technical support, let us know and fill in the answer form, we'll get back to you shortly.
